Products Description
| Specifications＆models | VK-D100M |
| Machining width | 250~3100mm |
| Machining Thickness | 10~50mm |
| Feeding Stop Spacing | 600mm |
| Feeding Speed | 5~25m/min |
| Pre-switching Speed | 3000-9000r/min |
| Speed Of Milling Groove | 4000-6000r/min |
| Knife Specification | ɸ50~220(外径)*ɸ40(内孔) |
| Milling Slot Motor | 8kw(11HP)*6 |
| Milling Slot Motor | 8kw(11HP)*4(选配) |
| Feeding Motor | 5.5kw(7.5HP) |
| Width Modulation Motor | 1.5kw(2HP) |
| Litting Motor | 0.75kw(1HP)*2 |
| Air Speed Of Dust Suction System | 30~35m/s |
| Air Volume Of Dust Suction System | 240m³/min |
| Overall Size | 4850*4650*1820mm |
| Weight | 6100Kg |
